Superbox S7 Assembly Instructions
Welcome to your new Superbox S7! Please read through this setup manual carefully before beginning assembly. Estimated assembly time is 15-20 minutes.
Before You Begin
• Clear a flat, spacious area for assembly. Lay down a soft blanket to prevent scratching the panels.
• Do not fully tighten screws until all parts are aligned and in place.
• Keep small parts and plastic bags away from children.
What's in the Box
Bottom Panel
x1
Side Panels
x2
Top Panel
x1
Back Panel
x1
Screws (M4)
x16
Front Door
x1
Tools Needed
Phillips Screwdriver
Included in the box
Attach Side Panels to Base Superbox S7
Take the Bottom Panel (A) and align the two Side Panels (B) with the pre-drilled holes on the left and right edges.
Insert the Back Panel Superbox S7
Carefully slide the Back Panel (D) down along the inner grooves of the side panels until it rests completely on the bottom panel.
Secure the Top Panel Superbox S7
Place the Top Panel (C) onto the assembled structure. Make sure all edges align. Insert and tighten 4 screws into the top corners.
Install the Front Door Superbox S7
Align the hinges on the Front Door (E) with the pre-drilled holes on the right Side Panel. Secure using the remaining 8 screws.
Assembly Complete! Superbox S7
Congratulations! You have successfully assembled your Superbox S7. Double-check all screws to ensure they are tight before use.
